Lighted self-lock button (NL22-11ZEP)
Specifications
| Brand | NAILE |
|---|---|
| Unit | pcs |
| Series | NL metal push button |
| Model | NL22-11ZEP |
| Mounting Size | 22 mm |
| Voltage | AC/DC 6/12/24/110/220 V; другие напряжения on request |
| Current Rating | 3A/250VAC |
| Contact Scheme | 1NO+1NC / 2NO+2NC |
| Action Type | Self-locking |
| Housing Material | Stainless steel |
| Protection Degree | IP67, IK10 |
| Colors | Red; green; yellow; blue; white |
| Source Page | 10 |
| Source | Naile Electric-Catalogue(New).pdf |
| Name En | Lighted self-lock button |
SKU: NL22-11ZEP
